Yamaha PSS170

Electronic keyboard

1986 (Dec.)
Initially sold for ¥18,400

The Yamaha PSS-170 is the successor to the PSS-160 and PSS-150, the entry level keyboard to the Portasound PSS line. 100 voices, 10 drum rhythms with fill-ins and an accompaniment section. Voices are based on a 2 operator FM synthesizer chip (the Yamaha YM2413) that can be slightly altered with sustain, vibrato, or portamento effects.

There's a single mono speaker, but it does have a headphone/aux connector.

Technical
specifications

Keyboard
44 keys

Sound source
FM tone generator (2 operators)

Memory capacity
100 preset voices
10 rhythms

Connection terminals and interfaces
Headphones/AUX

Dimensions and weight
629w x 56h x 192d (mm) / 24-3/4” x 2-1/4” x 7-1/2”
1.8Kg / 3.9lbs

Documents

Yamaha Portasound catalog (DE)
(pdf, 43 MB)

Demos

Just The Way You Are (version 1)
